This product is applied to the control circuit of a hydraulic system and changes the flow direction of oil line through the solenoid directional valve so as to meet the requirement on working conditions of the system. This kind of valves is widely used by all types of excavators.

Basic parameters:
1. Rated working pressure: PH=4MPa;
2. Rated flow QH=20L/min;
3. Rated working voltage: 24V DC;
4. Accumulator: 0.4L;Inflation pressure: 1.5MPa.
